Product Description
Classification
1500 hp Electric
Racking Capacity
18,000’
Power System
Three (3) Caterpillar 3512B/1225 generator sets One (1)Ross Hill SCR model 1400
Drawworks
National 110-UE with 7040 Baylor brake powered by Two (2) GE-752 traction motors
Mast
Superior 142′ Mast rated at 730,000 SHL
Drill Line
1-3/8” EIPS
Substructure
Pyramid 31′ high self-elevating substructure with 24′ 8″ clear height under beams with simultaneous rotary capacity of 750,000 lb with 450,000 lb setback
Mud Pumps
Three (3) Bomco F1600 triplex pumps each driven by Two (2) GE752 traction motors
Rotary
National 27-1/2” powered by One (1) GE 752 traction motor
Top Drive
NOV-TDS11 SA 500 ton
Block and Hook
National 400 ton block Web-Wilson 350 ton hook
Drill Pipe
5″ od 19.50 ppf S-135 NC 50
Annular Preventer
13-5/8” 5,000 psi wp with 10,000# flange
Ram Preventers
13-5/8″ 10,000 psi wp double ram 13-5/8″ 10,000 psi wp single ram
Choke Manifold
4-1/16″ x 3-1/16″ 10,000 psi wp
Accumulator System
240 gal seven (7) station with remote control
Mud System Three (3) Tank 1500 BBL System Three (3) Derrick 503 HG shakers One (1) 3 in 1 mud cleaner Vacuum Degasser
Auxillary Equipment
One (1) 500 BBL water tank Two (2) 12,000 gal fuel tanks NOV- Iron Roughneck type ST-80 C One (1) .092 Wireline unit Forum Pipe Wrangler
Features
| Quantity | 1 |
| Manufacturer | National |
| Model | 110UE |
| SKU | 121 |
| Location | Contact For Details |
| Price | Contact For Details |
